N-TRON PoE+ 4-Port Midspan-Injektor Übertragung von Strom und Daten über Ethernet-Netzwerke
N-TRON PoE+ 4-Port Midspan-Injektor1000-POE4+
N-TRON PoE+ 4-Port Midspan-Injektor
| Modell | N-TRON PoE+ Midspan-Injektor |
| Typ | PoE Midspan-Injektor |
| Gesamtanzahl Ports | 8 |
| 10/100/1000 Kupfer | 4 |
| Anzahl PoE+ Ports (IEEE 802.3at) | 4 |
| Gehäusematerial | Metall |
| Betriebstemperatur | -40°C ... +85°C |
| Abmessungen | 50,8 x 149,86 x 143,58 mm |
| Besonderheiten | MTBF: 2 Mio. Stunden Schock: 200G/10ms Vibration: 50G/Triaxial 5-200Hz ESD: +/- 16kV |
| Versorgungsspannung | 22-49 VDC |
| Übertragungsrate | 10/100/1000 Mbit/s |
| Montage | DIN-Hutschiene |
| Schutzgrad | IP20 |
| Zertifizierung | Product Safety: USA UL508 Industrial Control Equipment, ANSI/ISA 12.12.01-2015 Class I and II, Div. 2 and Class III, Div. 1 and 2, Groups A, B, C and D Hazardous Locations, T4 UL508 Industrial Control Equipment ANSI/ISA-12.12.01-2013, Class I and II,Division 2 and Class III, Divisions 1, Canada C22.2 No. 14; C22.2 No. 213-M1987 Class I, Division 2 Hazardous Locations, CAN/CSA-C22.2 No. 213-15, Hazardous Locations, CAN/CSA-C22.2 No. 14-13, Industrial Control Equipment, Emissions: FCC Title 47, Part 15, Radio Frequency Devices, Subpart B, ANSI C63.4-2009; Industry Canada ICES-003, EN 55032, EN 61000-3-2, EN61000-3-3, EN 55024, EN 61000-6-2, EN 61000-4-2 (ESD); EN 61000-4-3 (RFAM); EN 61000-4-4 (EFT); EN 61000-4-5 (SURGE); EN 61000-4-6 (RFCM); EN 61000-4-8 (PFMF); EN 61000-4-11 (VDI), Rail: EN 50155, EN50121, EN61373, ABS Type Approval for Shipboard Applications, Designed to Comply with: IEEE 1613 (Electric Utility Substations), NEMA TS1/TS2 (Traffic Control), EMC Directive 2014/30/EU, LV Directive 2014/35/EU GOST-R, RoHS |
